Specialty Morgan Service Unit featuring a worker on location
Engineered Mobile Service Solutions

Morgan Service Unit

Order availability coming soon

Whether you’re providing emergency roadside assistance, tire changes and battery / jump starts, or offering customers the convenience of on-site mobile repair, welding, oil changes, lubes, and field maintenance…

Morgan’s MSU is your repair shop on wheels!

Roadside Assistance Icon

Roadside Assistance

Field Maintenance Icon

Field Maintenance

Tire Service Icon

Tire Service

Mobile Repair & Welding Icon

Mobile Repair & Welding

Battery & Jump Start Icon

Battery & Jump Start

Oil & Lube Icon

Oil & Lube

Morgan Service Unit Rear 3/4 Animation

Standard Features

Base Body Specifications

  • Length: 16' and 18'
  • Width: 96"
  • Height: 91"
  • Subframe: 12" Centers, 4" Long Rail
  • Floor: Aluminum Anti-Skid Inverted T
  • Rear Frame: Stainless Steel
  • Roof: Translucent Roof with Aluminum Radi
  • Wall Panels: White Morganplate
  • Maximizer Canister Roll-Up Door: Curbside
  • Rear Finish: Standard Underride
  • Vents:

      • Two [2] Vents in Front Wall Upper Corners

      Two [2] Vents in OHD Door Bottom Panel, Curbside and Roadside

Power Center

  • Vanair ANA-150, 20HP Gas Engine

      • 20 CFM Air Compressor

      4.2 kW Generator 120/240 VAC

      Jump Start/Charge: 150A 12/24V Boost 50A Charge

      Welder: 40 - 150 AMP DC/CC, 15 – 30V DC/CV

      25 ft. Welding Cables and 20 ft. Jumper Cable

  • 30 Gal Remote Air Tank, Mounted Roadside Underbody
  • Reelcraft Air Reel

Workbench

  • Workbench with Exterior Access Compartments

      • 114"L x 30"D x 36"H

  • Aluminum Wall-Mounted Shelves Above Workbench

      • 60"W x 18"D

      54"W x 18"D

Lighting

  • Interior - Four 18" Rectangular LED Lights [MSE]
  • Rear - Two LED Spot Lights on Rear Header [MSE]
  • Three Tecniq K90 White LED Scene Lights on Curbside of Body
  • One Radius Light Above Maximizer Door
  • One Light in Exterior Access Compartment with Door Switch
  • One Safety Director / Strobe Bar Mounted on Rear Header with Controller in Cab
  • Toggle Switches Mounted Inside Body for Lighting

      • Switches at Side Door and Curbside Rear

      Dome Lights 3-Way Switches at Side Door and Rear

      Scene Lights 3-Way Switches at Side Door and Rear

      Radius Light Switch at Side Door

      Rear Spot Light Switch at Rear

Safety Features

  • Additional Conspicuity Tape Both Sides of Body Top Rail, and Vertical Connectors
  • Combination Carbon Monoxide / Smoke Detector
  • Two [2] 10 lb. ABC Fire Extinguishers Inside the Body
  • Two [2] 36" Grab Handles Inside Rear Frame Opening at Standard Height
  • Two [2] Grab Handles on Exterior of Maximizer Door Frame Left and Right Sides
  • Fiberglass Tread Plate Covers at Maximizer Stepwell with Coarse Coating
  • Sidedoor Stepwell Handrail
  • Wheel Chocks
  • Cone Holder with Three [3] 28" Cones
  • Eye Wash Station, Mounted on Wall
  • First Aid Kit, Mounted on Wall
  • 20 Gal Oil Spill Kit, Mounted on Wall

Optional Equipment

Morgan Service Unit Liftgate

Optional Liftgates

  • Waltco MDL Liftgate

      • 2000 lb. Capacity

      Aluminum Platform 89x42+6

  • Waltco DDL Hi-Lift Rail Gate

      • 2000 lb. Capacity

      Aluminum Bar Grating Platform 89x42+12 Ramp

  • Dhollandhia DHOV Hi-Lift Rail Gate
  • Maxon TE-20 Tuk-Away

Optional Upgrades

  • Oil and Lube Package
  • 2000 Watt Inverter with Integrated 80 Amp Battery Charger
  • Two 12V DC Auxiliary Batteries
  • Tire Holder
  • Steel Shelving Unit

      • 51"W X 16"D X 60"H with 5 Shelves

      Mounted on Front Wall

  • Steel Cabinet

      • 36"W X 18"D X 72"H, Cabinet, with 4 Shelves

      Mounted on Front Wall

Situational Awareness

Situational Awareness Package
Situational Awareness Package

Situational Awareness Package featuring digital rear-view mirror, back up proximity sensors, 360 degree and internal cargo area cameras, and supplemental hazard detection to alert driver of potential hazards in or around the truck.

Interactive Cargo Area 360

Use your mouse or finger to rotate the interactive 360 tour.

Gallery

Want to know more?

Morgan Service Unit brochure cover

Morgan Service Unit Brochure

Take it with you by downloading the Morgan Service Unit brochure PDF, providing a portable and comprehensive overview to effortlessly share the key highlights with your valued customers and stakeholders.

View Brochure
Front 3/4 Morgan Service Unit view

Connect with Us

Step into the next generation of delivery solutions by reaching out to Morgan Truck Body today and discover how their innovative concept truck bodies can revolutionize your fleet's efficiency and performance.
